When you're setting up a bench for electronic testing, the fixture you choose can mean the difference between a quick check and a frustrating session. Two very different options in the test leads, probes, and fixtures space are the Tektronix Diode Test Fixture Adapter 013-072 and the Data Recovery Fixture Chip Recovery Test Fixture with 10 probes. One is a plug-in adapter; the other is a positioning fixture. The right choice depends on the jobs that actually show up at your workbench.
Quick Verdict
If your work centers on instrument restoration and benchtop testing, the Tektronix 013-072 is the direct adapter you'll reach for. If you're repairing damaged circuit boards and soldering flying wires, the Data Recovery Fixture with its probe system is the more flexible pick.
Comparison
| Feature | Tektronix Diode Fixture | Data Recovery Fixture |
|---|---|---|
| Price | USD 89.99 | USD 66.49 |
| Connection / Outputs | Banana plug outputs and center jack | Adjustable stainless steel probe needles (10 included) |
| Typical Work | Diode testing, lab repair, vintage restoration | Data recovery, chip repair, soldering flying wires |
| Design | Compact plug-in adapter | Board-mounted fixture with movable probe arm |
Where Each Product Wins
The Tektronix wins for dedicated diode testing, thanks to its straightforward adapter design and terminal layout. For someone who works on vintage Tektronix instruments, the familiar labeling and form factor are a bonus.
The Data Recovery Fixture wins for chip-level repair, where its probe system gives you more control during soldering and data recovery tasks. Precise probe placement is the whole point, and this fixture is built for that.
Product Notes
Tektronix Diode Test Fixture Adapter 013-072
This plug-in adapter brings classic Tektronix labeling to your test bench. It has two banana plug outputs and a center jack, with terminal markings for E and C, and the plastic housing with metal banana terminals makes it easy to connect into a diode test setup. If your work involves restoring older instruments, this is the kind of fixture that fits naturally into that process. Its plug-in design means you can connect it directly to test equipment, making it handy for quick tests. The main limitation is its focus: it's built for diode testing and lab repair, not for holding and positioning probes over a chip. The Data Recovery Fixture is the better match for that kind of work.
Data Recovery Fixture Chip Recovery Test Fixture
This fixture is all about getting probes exactly where you need them. The probe can move forward and backward, up and down, and its position is adjustable, which is a huge help when you're soldering flying wires to repair data damage on a circuit board. It comes with a set of stainless steel probes with 0.8 mm needles, and the circuit board base measures 151×135 mm with a weight of about 300 g. That adjustability is the key advantage when you need to hold a needle steady while you solder. The limitation is that it is not designed for simple diode testing; it is a positioning fixture for chip recovery and soldering tasks. If your bench work revolves around data recovery, this tool directly supports that workflow.
Final Choice by Use Case
If you repair Tektronix equipment and need a dedicated diode test adapter, the Tektronix 013-072 is the one. If you repair chips or solder flying wires, the Data Recovery Fixture is the practical choice. For a bench that does a little of both, the $23.50 price spread matters: the Data Recovery Fixture is $66.49 and includes 10 probes, while the Tektronix is $89.99 for the classic adapter. Let the dominant type of work on your bench decide.
